Kp75kw-0.8mpa-1.6mpa Efficient And Energy Saving Double Stage Air Compressor

  • Kp75kw-0.8mpa-1.6mpa Efficient And Energy Saving Double Stage Air Compressor
  • Kp75kw-0.8mpa-1.6mpa Efficient And Energy Saving Double Stage Air Compressor
  • Kp75kw-0.8mpa-1.6mpa Efficient And Energy Saving Double Stage Air Compressor
  • Kp75kw-0.8mpa-1.6mpa Efficient And Energy Saving Double Stage Air Compressor
  • Kp75kw-0.8mpa-1.6mpa Efficient And Energy Saving Double Stage Air Compressor
  • Kp75kw-0.8mpa-1.6mpa Efficient And Energy Saving Double Stage Air Compressor
  • Kp75kw-0.8mpa-1.6mpa Efficient And Energy Saving Double Stage Air Compressor
  • Kp75kw-0.8mpa-1.6mpa Efficient And Energy Saving Double Stage Air Compressor
Place of Origin CHINA
Brand Name Kapa
Certification CE,SGS,ISO14001
Model Number double stage
Minimum Order Quantity 1
Price USD 12409-12690 PER UNIT
Packaging Details Ply-wood case
Delivery Time 25-30
Payment Terms L/C, T/T
Supply Ability 1000 SET PER MONTH
Product Details
Type Kapa Double Stage Air Compressor Capacity/Pressure (m3/min/MPa 17.6-16.5/0.8-1.6
Lubricating Oil (L) 90 Oil Content W 3-5ppm
Drive Method Direct Driven Start Way PM VSD
Noise Db (A) 70-74 Dimension （mm） 2180*1430*1720
Weight (kg) 1620 Condition Brand New
Gas Type Air Working Pressure 8-16bar
High Light

0.8mpa Double Stage Air Compressor

,

1.6mpa Double Stage Air Compressor

,

75kw Two Stage Screw Air Compressor
You can tick the products you need and communicate with us in the message board.
Power (KW) 22 37 45 55 75 90 110
Capacity/Pressure (m3/min/MPa) 4.6-4.1/ 8.0-7.1/ 10.9-9.7/ 13.4-12/ 17.6-16.5/ 20/0.8 24/0.8
Lubricating oil (L) 18 54 72 90 90 110 110
Oil content W 3-5ppm W 3-5ppm W 3-5ppm W 3-5ppm W 3-5ppm W 3-5ppm W 3-5ppm
Drive method Direct driven Direct driven Direct driven Direct driven Direct driven Direct driven Direct driven
Start way PM VSD PM VSD PM VSD PM VSD PM VSD PM VSD PM VSD
Noise db (A) 60~70±2 60~70±2 60~70±2 60-70±2 70-74 70-74 70-74
Length (mm) 1580 1880 2180 2180 2180 2780 2780
Width (mm) 1080 1180 1430 1430 1430 1580 1580
Height (mm) 1290 1520 1720 1720 1720 2160 2160
Weight (Kg) 660 950 1530 1580 1620 2100 2900
Power (KW) 132 160 200 220 250 315
Capacity/Pressure (m3/min/Mpa) 26.95/0.8 33/0.8 45.71/0.8 47/0.8 54/0.8 63/0.8
Lubricating oil (L) 125 125 175 175 200 200
Drive method Direct driven Direct driven Direct driven Direct driven Direct driven Direct driven
Start way PM VSD PM VSD PM VSD PM VSD PM VSD PM VSD
Noise db (A) 78-82 78-82 78-82 78-82 78-82 78-82
Length (mm) 2980 2980 3650 3650 3650 3650
Width (mm) 1880 1880 1980 1980 1980 1980
Height (mm) 2160 2160 2150 2150 2150 2150
Weight (Kg) 3050 3850 5300 5300 5400 5600
Leave a Message
Power (KW) 22 37 45 55 75 90 110
Product Description

kp75kw-0.8mpa-1.6mpa Effcient and Energy saving double stage air compressor​.



Specification



Model

Motor

Power

HP/KW

 Lubricating oil (L)

Capacity

M3/min



Pressure

MPA

 Noise db (A)



Dimension

mm



Weight

kg
kp75kw-0.8-1.6mpa 75KW/100HP 90 17.6-16.5 0.8-1.6 70-74 2180*1430*1720 1620



Kp75kw-0.8mpa-1.6mpa Efficient And Energy Saving Double Stage Air Compressor 0





The Other KAPA Air Compressors:



1) Screw Air Compressors ( Air delivery:0.8m³/min -72m³/min;Work pressure:8-13Bar;Power:7.5Kw-415kw)



2) Mining Air Compressors(Air delivery:1.8m³/min-13m³/min ;Work pressure:5-7Bar;Power 11Kw-108Kw)



3) Diesel Driven Portable Screw Air Compressors (Air delivery:6m³/min-1377m³ ,Work pressure:7-35Bar )



4) Motor Powered Portable Screw Air Compressors -(350CFM – 910CFM)



5) Explosion Proof Air Compressors - 30HP-120HP (22kw-90kw)



6) Diesel Driven Piston Small Air Compressors -15HP-25HP (11kw-18.5kw)



Working diagram



55KW Two Stage Screw Air Compressor 7.5~10.5 m³/min 1900mm * 1240mm * 1700mm













































1. Air Filter

2. Air-in Easing Value

3. Air end

4. Oil Air Separator

5. Oil Air Separating Filter Core

6. Minimum Pressure Valve

7. Radiator with Aluminum Alloy Fans

8. Return Check Valve

9. Oil Temperature Control Valve

10. Oil Filter

11. One-way Shut-off Valve

12. Pressure Gage

13. Safety Valve

14. Vent Valve

15. Compressed Air Dry Separator

16. Motor







Advantages of Kapa brand



Innovate technology to protect the environment.

Kapa listens, understands and meets the needs of customers

Save the environment, ensure to provide better services and solutions, save costs for users, and seek the largest growth space. The main purpose is to protect and save energy, stimulate the growth of economic productivity, comply with market demand, save energy and reduce environmental pollution. With the mission of "innovation embodies value", Kapa Company will continue to promote technological innovation and progress, achieve win-win with global partners, suppliers and employees, create a new world of "energy saving, environmental protection, intelligence and service" in the aerodynamic field, and strive to be a world-class enterprise with world-class standards.



Advantages:


1. High quality control(CE,SGS,ISO14001/Energy saving certificate)
2. Fast Delivery( 25-30 days for large orders)
3. Good service for pre-sale,after-sale( strong technical support and professional after-sales team)
4. Small order acceptable( Ordering quantity according to your actual needs)





Why choose us



Longer service life of the master machine
The rotor uses asymmetrical line running at a low speed with the support of the ball bearings and roller bearings as a result. The damage and the cost are lowered and the service life is extended. Some force is counteracted by the axial force generated by the bevel gear. So the load on the bearings of the master machine is lowered.
Permanent alignment of the electromotor and the master machine
Different from the strap compressor, the SRC series compressor can integrate the electromotor with flange, shaft coupling box-gear box. and the master machine into one in such way the master machine and the electrometer are aligned forever in the transpiration. The SRC series compressors equipped with effective and fully sealed air-cooling electromotor.



FAQ



Q1: Are you factory or trade company?
A1: We are factory. And we have ourselves trading company.
Q2: What the exactly address of your factory?
A2: Our company is located in Zone B, Lianhua County Industrial Park, Pingxiang City, Jiangxi Province of ChinaQ3: Warranty terms of your machine?
A3: One year warranty for the machine and two years for air end
Q4: Will you provide some spare parts of the machines?
A4: Yes, of course.
Q5: What about the voltage of products? Can they be customized?
A5: Yes, of course. The voltage can be customized according to your equirement.
Q6: Which payment term can you accept?
A6: 30% T/T in advanced, 70% T/T against the B/L copy.
Q7: How long will you take to arrange production?
A7: 380V 50HZ we can delivery the goods within 10 -15 days. Other electricity or other color we will delivery within 25-30 days.
Q8: Can you accept OEM orders?
A8: Yes, with professional design team, OEM orders are highly welcome.
Q9: Which trade term can you accept?
A9: Available trade terms: FOB, CIF, CFR, EXW, CPT, etc.
