Kp45kw-0.8mpa-1.6mpa Efficient And Energy Saving Double Stage Air Compressor

Kp45kw-0.8mpa-1.6mpa Efficient And Energy Saving Double Stage Air Compressor

  • High Light

    45KW Double Stage Air Compressor

    ,

    60HP Double Stage Air Compressor

    ,

    SGS Two Stage Screw Air Compressor

  • Type
    Kapa Double Stage Air Compressor
  • Capacity/Pressure (m3/min/MPa)
    4.6-4.1/ 0.8mpa-1.6mpa
  • Lubrication Oil (L)
    72
  • Oil Content
    W 3-5ppm
  • Drive Method
    Direct Driven
  • Start Way
    PM VSD
  • Noise Db (A)
    60~70±2
  • Dimension (mm)
    2180*1430*1720
  • Weight (kg)
    1530
  • Condition
    Brand New
  • Voltage
    380V/220V/415V
  • Power Source
    AC POWER
  • Place of Origin
    CHINA
  • Brand Name
    Kapa
  • Certification
    CE,SGS,ISO14001
  • Model Number
    double stage
  • Minimum Order Quantity
    1
  • Price
    USD 10596 -10712PER UNIT
  • Packaging Details
    Ply-wood case
  • Delivery Time
    25-30
  • Payment Terms
    L/C, T/T,
  • Supply Ability
    1000 SETS PER MONTH

Kp45kw-0.8mpa-1.6mpa Efficient And Energy Saving Double Stage Air Compressor

kp45kw-0.8mpa-1.6mpa Effcient and Energy saving double stage air compressor​​.



Specification



Model

Motor

Power

HP/KW

Lubricating oil (L)

Capacity

M3/min



Pressure

MPA

Noise db (A)



Dimension

mm



Weight

kg



kp45kw-0.8-1.6mpa



45KW/60HP

72



10.9-9.7



0.8-1.6

60~70±2

2180*1430*1720



1530



Kp45kw-0.8mpa-1.6mpa Efficient And Energy Saving Double Stage Air Compressor 0



Application



The series air compressor is widely applicable to auto repair, machinery, electronics, plastics, mining, hydropower, engineering, chemical, drilling. Blow molding machine, punch press, printing, food, transportation and other equipment, powerful, suitable for many fields.



Kp45kw-0.8mpa-1.6mpa Efficient And Energy Saving Double Stage Air Compressor 1











Characteristics


1. Strongly power -driven and big air end with design,the air compressor owns bigger and heavier main parts than other products in the same trade with better selection and sufficient using of materials especially with main fittings.In addition, it is more suitable to pe applied in the continuous operation under heavy load for long woring time with higher reliability and longer lifespan.



2. Special designed is made in heat emission and air flow,which leads to low air-output temperature and low possibility of carbon deposit.



3. Composite ring valve is adopted in design.with the valve plate made of stainless steel from Sweden and the spring of valve block made of special spring steel wire from Japan with no bending motion in operation ,the valve processes excellent properly and ideal lifespan index.



4. Crankshaft undergoes high-frequency hardening,which enables it especially abrasion-proof.



5. Some relevant working units are received precision balance,which makes it more stable with lower noise.



6. Special oil separation construction is built inside the fronted jackets,so no oil vents from the breather valve ,which ensures low oil consumption and deanness of machine body.



7. The core of air filter is made of imported filter paper ,which acts well in filtering and absorbing noise.



8. With rational design in the flaring angle of copper socket pipe and protecting jacket,it avoids cracking and air leaking.



9. Pressure switch ,contactor unit and thermorelay are imported with famous brands as “schneider” to ensure the reliability in control and protection.



10. The are four types available in controlling air flow as automatically air controlled,electric and air controlled (manually switch),and intelligent two-way controlled one,which cater to different demand of customers.



11. If the air delivery condition is complex ,the intelligent controller is recommended to be installed ,which is a device that can switch automatically between two different modes as electric or air controlled when feeling the condition of air delivery.





Advantages of Kapa brand



Innovate technology to protect the environment

Kappa listens, understands and meets the needs of customers

Save the environment, ensure to provide better services and solutions, save costs for users, and seek the largest growth space. The main purpose is to protect and save energy, stimulate the growth of economic productivity, comply with market demand, save energy and reduce environmental pollution. With the mission of "innovation embodies value", Kappa Company will continue to promote technological innovation and progress, achieve win-win with global partners, suppliers and employees, create a new world of "energy saving, environmental protection, intelligence and service" in the aerodynamic field, and strive to be a world-class enterprise with world-class standards.



Advantages:


1. High quality control(CE,SGS,ISO14001/Energy saving certificate)
2. Fast Delivery( 25-30 days for large orders)
3. Good service for pre-sale,after-sale( strong technical support and professional after-sales team)
4. Small order acceptable( Ordering quantity according to your actual needs)



Why choose us



Longer service life of the master machine
The rotor uses asymmetrical line running at a low speed with the support of the ball bearings and roller bearings as a result. The damage and the cost are lowered and the service life is extended. Some force is counteracted by the axial force generated by the bevel gear. So the load on the bearings of the master machine is lowered.
Permanent alignment of the electromotor and the master machine
Different from the strap compressor, the SRC series compressor can integrate the electromotor with flange, shaft coupling box-gear box. and the master machine into one in such way the master machine and the electrometer are aligned forever in the transpiration. The SRC series compressors equipped with effective and fully sealed air-cooling electromotor.



FAQ



Q1: Why customers choose Kapa?

A: KAPA has 20 years of experiences specialized in screw air compressor industry. R & D team and engineers originally from Sullair, with SGS and ISO certified management and control system. We warmly welcome your small trial order for quality and market test.

Q2: Are you a direct manufacturer or just a trading company?

A:We are a professional manufacturer with big modern workshops situated in Pingxiang Lianhua Industrial Park,Jiangxi Province, China. Both OEM & ODM service are available.

Q3: How about your delivery time?

A: Generally 25-30 days. While if ordering special designs or customized models, shipping time will be somewhat longer. Exact time please contact sales in advance to confirm then.

Q4: HOW LONG IS YOUR AIR COMPRESSOR WARRANTY?

A: One Year for the whole machine and two years for screw air-end.

Q5: HOW ABOUT YOUR AFTER-SALES SERVICE?

A:We provide customers with installation and commissioning online instructions.well-trained engineer will troubleshoot within 24-48 hours through online videos or calls.
