Kp315kw-0.8mpa 380V/220V/415V Efficient And Energy Saving Double Stage Air Compressor

Kp315kw-0.8mpa 380V/220V/415V Efficient And Energy Saving Double Stage Air Compressor

  • High Light

    1HP Piston Air Compressor

    ,

    0.75KW Piston Air Compressor

    ,

    1HP High Pressure Air Compressor

  • (M³/Min/Mpa)
    61.79/0.8
  • Discharge Temp
    ≤Ambient +15℃
  • Noise Level Db(A)
    78
  • Driven Mode
    Direct Drive
  • Power (V/Ph/Hz)
    380V/220V/415V 50HZ/60HZ
  • Dimension (mm)
    2980*1880*2160
  • Net Weight (kg)
    5600kg
  • Place Of Origin
    China Mainland
  • Place of Origin
    CHINA
  • Brand Name
    Kapa
  • Certification
    CE,SGS,ISO14001
  • Model Number
    double screw
  • Minimum Order Quantity
    1
  • Price
    USD 50591-55363
  • Packaging Details
    Ply-wood case
  • Delivery Time
    25-30 days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    5000PER MONTH

Kp315kw-0.8mpa 380V/220V/415V Efficient And Energy Saving Double Stage Air Compressor

kp315kw-0.8mpa 380V/220V/415V Effcient and Energy saving double stage air compressor.



Specification



Model

Motor

Power

HP/KW

Lubricating oil (L)

Capacity

M3/min



Pressure

MPA

Noise db (A)



Dimension

mm



Weight

kg

kp315kw-0.8 315KW/430HP 125 61.79 0.8 78-82 3650*1980*2150



Kp315kw-0.8mpa 380V/220V/415V Efficient And Energy Saving Double Stage Air Compressor 0


Application



The series air compressor is widely applicable to auto repair, machinery, electronics, plastics, mining, hydropower, engineering, chemical, drilling. Blow molding machine, punch press, printing, food, transportation and other equipment, powerful, suitable for many fields.



Kp315kw-0.8mpa 380V/220V/415V Efficient And Energy Saving Double Stage Air Compressor 1







More models:

Power (KW) 22 37 45 55 75 90 110
Capacity/Pressure (m3/min/MPa) 4.6-4.1/ 8.0-7.1/ 10.9-9.7/ 13.4-12/ 17.6-16.5/ 20/0.8 24/0.8
0.8-1.6 0.8-1.6 0.6-0.9 0.8-1.6 0.8-1.6
Lubricating oil (L) 18 54 72 90 90 110 110
Oil content W 3-5ppm W 3-5ppm W 3-5ppm W 3-5ppm W 3-5ppm W 3-5ppm W 3-5ppm
Drive method Direct driven
Start way PM VSD
Noise db (A) 60~70±2 60~70±2 60~70±2 60-70±2 70-74 70-74 70-74
Length (mm) 1580 1880 2180 2180 2180 2780 2780
Width (mm) 1080 1180 1430 1430 1430 1580 1580
Height (mm) 1290 1520 1720 1720 1720 2160 2160
Weight (Kg) 660 950 1530 1580 1620 2100 2900

Power (KW) 132 160 200 220 250 315
Capacity/Pressure (m3/min/Mpa) 26.95/0.8 33/0.8 45.71/0.8 47/0.8 54/0.8 63/0.8
Lubricating oil (L) 125 125 175 175 200 200
Drive method Direct driven
Start way PM VSD
Noise db (A) 78-82 78-82 78-82 78-82 78-82 78-82
Length (mm) 2980 2980 3650 3650 3650 3650
Width (mm) 1880 1880 1980 1980 1980 1980
Height (mm) 2160 2160 2150 2150 2150 2150
Weight (Kg) 3050 3850 5300 5300 5400 5600



Advantages of Kapa brand



Innovate technology to protect the environment.Kappa listens, understands and meets the needs of customers.Save the environment, ensure to provide better services and solutions, save costs for users, and seek the largest growth space. The main purpose is to protect and save energy, stimulate the growth of economic productivity, comply with market demand, save energy and reduce environmental pollution. With the mission of "innovation embodies value", Kappa Company will continue to promote technological innovation and progress, achieve win-win with global partners, suppliers and employees, create a new world of "energy saving, environmental protection, intelligence and service" in the aerodynamic field, and strive to be a world-class enterprise with world-class standards.



Advantages:


1. High quality control(CE,SGS,ISO14001/Energy saving certificate)
2. Fast Delivery( 25-30 days for large orders)
3. Good service for pre-sale,after-sale( strong technical support and professional after-sales team)
4. Small order acceptable( Ordering quantity according to your actual needs)



why choose us



Longer service life of the master machine
The rotor uses asymmetrical line running at a low speed with the support of the ball bearings and roller bearings as a result. The damage and the cost are lowered and the service life is extended. Some force is counteracted by the axial force generated by the bevel gear. So the load on the bearings of the master machine is lowered.
Permanent alignment of the electromotor and the master machine
Different from the strap compressor, the SRC series compressor can integrate the electromotor with flange, shaft coupling box-gear box. and the master machine into one in such way the master machine and the electrometer are aligned forever in the transpiration. The SRC series compressors equipped with effective and fully sealed air-cooling electromotor.



FAQ



Q1: Why customers choose Kapa?

A: KAPA has 20 years of experiences specialized in screw air compressor industry. R & D team and engineers originally from Sullair, with SGS and ISO certified management and control system. We warmly welcome your small trial order for quality and market test.

Q2: Are you a direct manufacturer or just a trading company?

A:We are a professional manufacturer with big modern workshops situated in Pingxiang Lianhua Industrial Park,Jiangxi Province, China. Both OEM & ODM service are available.

Q3: How about your delivery time?

A: Generally 25-30 days. While if ordering special designs or customized models, shipping time will be somewhat longer. Exact time please contact sales in advance to confirm then.

Q4: HOW LONG IS YOUR AIR COMPRESSOR WARRANTY?

A: One Year for the whole machine and two years for screw air-end.

Q5: HOW ABOUT YOUR AFTER-SALES SERVICE?

A:We provide customers with installation and commissioning online instructions.well-trained engineer will troubleshoot within 24-48 hours through online videos or calls.
