Two Stage 15.15m3/min 75KW 100hp Screw Air Compressor

Two Stage 15.15m3/min 75KW 100hp Screw Air Compressor

  • High Light

    100hp Screw Air Compressor

    ,

    75KW Screw Air Compressor

    ,

    100hp Screw Type Air Compressor

  • Type
    Screw Air Compressor
  • (M³/Min/Mpa)
    15.15/0.8
  • Power Kw/HP
    75KW/100HP
  • Ambient Temperature℃
    2℃-45℃
  • Cooling Mode
    Air Cooling
  • Discharge Temp
    ≤Ambient +15℃
  • Lub Oil Capacity
    42.3L
  • Noise Level
    78
  • Drive Mode
    Direct Drive
  • Power(V/PH/HZ)
    380V/50HZ
  • Dimension(mm)
    2180*1430*1720
  • Net Weight
    1620kg
  • Out Let Diameter(inch)
    RP2
  • Condition
    New
  • Place of Origin
    CHINA
  • Brand Name
    Kapa
  • Certification
    CE ISO SGS
  • Model Number
    KP75-0.8II
  • Minimum Order Quantity
    1
  • Price
    USD 13591 PER UNIT
  • Packaging Details
    Ply Wood box
  • Delivery Time
    25-30 days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    2000 SETS PER MONTH

Two Stage 15.15m3/min 75KW 100hp Screw Air Compressor

75KW / 100hp Two Stage Screw Air Compressor 15.15m³ / min 2180*1430*1720

Description

Save energy 10-15% compare with one stage;
The compression efficiency is 12-18% higher than one stage;
Vibration is 15-30% lower than one stage.


Double stage compression structure,more energy saving.
compression and high efficiency screw machine is a low pressure ratio,a greater degree of lower volume leakage to improve energy efficiency!

The core is the two-level compression of the injection screw air compressor in the same power than the single-stage compression of the injection screw air compressor and more12%-23% air volume

Low vibration to make the unit running more stable
Lower than ordinary screw speed,and the use of multiple damping springs,so that the unit has a higher stability
Low speed noise
Using large rotor to reduce the unit speed,full load speed in the 2000RPM is a more quiet guarantee



Screw air compressor has unique structure design, compact structure, unique appearance, high efficiency, low energy consumption, low noise and long service life, etc., which is an intelligent and environmental protection product. It is an ideal gas source equipment widely used in metallurgy, machinery, chemical industry, geology and mining, electric power and other industrial fields.







Two Stage 15.15m3/min 75KW 100hp Screw Air Compressor 0



Specification



Model Specification KP75-0.8II
Displacement/Pressure (M³/Min/Mpa) 15.15/0.8
Power Kw/ HP 75KW/100HP
Ambient Temperature ℃ 2℃-45℃
Cooling Mode Air-Cooling
Discharge Temp ≤Ambint+15℃
Lub Oil Capacity Liter 42.3L
Noise Level Db(A) 78
Driven Mode Direct Drive
Power V/Ph/Hz 380V/50Hz
Starting Mode power frequency
Dimension mm 2180*1430*1720
Net Weight kg 1620
Out let Diameter inch RP2







Two Stage 15.15m3/min 75KW 100hp Screw Air Compressor 1











Advantages of Kapa brand

Innovate technology to protect the environment

Kappa listens, understands and meets the needs of customers

Save the environment, ensure to provide better services and solutions, save costs for users, and seek the largest growth space. The main purpose is to protect and save energy, stimulate the growth of economic productivity, comply with market demand, save energy and reduce environmental pollution. With the mission of "innovation embodies value", Kappa Company will continue to promote technological innovation and progress, achieve win-win with global partners, suppliers and employees, create a new world of "energy saving, environmental protection, intelligence and service" in the aerodynamic field, and strive to be a world-class enterprise with world-class standards.



Advantages:
1. High quality control(ISO 9001-2000/ISO14001/ASME/Energy saving certificate)
2. Fast Delivery( 10-15 days for large orders)
3. Good service for pre-sale,after-sale( strong technical support and professional after-sales team)
4. Small order acceptable( Ordering quantity according to your actual needs)

why choose us



Longer service life of the master machine
The rotor uses asymmetrical line running at a low speed with the support of the ball bearings and roller bearings as a result. The damage and the cost are lowered and the service life is extended. Some force is counteracted by the axial force generated by the bevel gear. So the load on the bearings of the master machine is lowered.
Permanent alignment of the electromotor and the master machine
Different from the strap compressor, the SRC series compressor can integrate the electromotor with flange, shaft coupling box-gear box. and the master machine into one in such way the master machine and the electrometer are aligned forever in the transpiration. The SRC series compressors equipped with effective and fully sealed air-cooling electromotor.

FAQ

Q1: Are you factory or trade company?
A1: We are factory. And we have ourselves trading company.
Q2: What the exactly address of your factory?
A2: Our company is located in Zone B, Lianhua County Industrial Park, Pingxiang City, Jiangxi Province of China

Q3: Warranty terms of your machine?
A3: One year warranty for the machine and technical support according to your needs.
Q4: Will you provide some spare parts of the machines?
A4: Yes, of course.
Q5: What about the voltage of products? Can they be customized?
A5: Yes, of course. The voltage can be customized according to your equirement.
Q6: Which payment term can you accept?
A6: 30% T/T in advanced, 70% T/T against the B/L copy.
Q7: How long will you take to arrange production?
A7: 380V 50HZ we can delivery the goods within 10 -15 days. Other electricity or other color we will delivery within 25-30 days.
Q8: Can you accept OEM orders?
A8: Yes, with professional design team, OEM orders are highly welcome.
Q9: Which trade term can you accept?
A9: Available trade terms: FOB, CIF, CFR, EXW, CPT, etc.
